R22 PT Chart Pressure Temperature: Complete Technical Reference 2026

As an HVAC technician with over 15 years of experience servicing refrigeration systems, I’ve found that understanding R22 pressure-temperature relationships is fundamental to proper system diagnosis and charging. An R22 PT chart is a reference table showing the saturation pressure at various temperatures, essential for anyone working with HCFC-22 refrigerant systems.

An R22 PT chart displays the pressure-temperature relationship for R22 refrigerant, showing how pressure changes predictably with temperature – as temperature increases, pressure increases according to thermodynamic properties of the refrigerant. This reference is essential for HVAC technicians to properly charge systems, diagnose problems, and ensure efficient operation of air conditioning and refrigeration equipment.

In this comprehensive guide, you’ll find complete pressure-temperature data, practical charging procedures, troubleshooting techniques, and real-world field examples that I’ve gathered from thousands of service calls. Whether you’re a seasoned technician or HVAC student, this reference will help you work more effectively with R22 systems.

Complete R22 Pressure-Temperature Chart

The following table shows saturation pressures for R22 at various temperatures, which is the core reference data you’ll need in the field. I’ve included both Fahrenheit and Celsius temperatures, with pressures in PSIG (pounds per square inch gauge), which is the standard measurement used in HVAC work.

Temp (°F)	Temp (°C)	Pressure (PSIG)	Application Notes
-60	-51.1	21.9	Deep freeze applications
-50	-45.6	26.8	Low temperature refrigeration
-40	-40.0	32.1	Freezer evaporator temp
-30	-34.4	37.9	Medium temperature refrigeration
-20	-28.9	44.3	Standard refrigeration
-10	-23.3	51.2	High temp refrigeration
0	-17.8	58.7	Ice point reference
10	-12.2	66.8	Cold room applications
20	-6.7	75.5	Air conditioning low side
30	-1.1	84.9	Standard AC operation
40	4.4	94.9	Typical evaporator temp
45	7.2	100.4	Optimal cooling temp
50	10.0	106.2	High efficiency range
55	12.8	112.2	Peak performance range
60	15.6	118.6	Warm weather operation
70	21.1	132.2	High ambient conditions
80	26.7	146.9	Very high ambient
90	32.2	162.7	Extreme conditions
100	37.8	179.8	Maximum operating range
110	43.3	198.1	High pressure warning
120	48.9	217.7	Above normal range
130	54.4	238.7	High pressure limit
140	60.0	261.1	Critical approach
150	65.6	285.0	Near critical pressure
155	68.3	297.5	Approaching critical

Understanding R22 Pressure-Temperature Relationships

The pressure-temperature relationship in R22 follows predictable physical laws that govern how refrigerants behave under different conditions. Understanding these relationships is crucial for proper system diagnosis and charging. When I work on R22 systems, I constantly reference these relationships to verify system performance.

Saturation pressure is the pressure at which refrigerant changes phase at a given temperature, and this is the core principle behind PT charts. For R22, this relationship means that at 40°F, the refrigerant will be at 94.9 psig when it’s boiling (evaporating) or condensing. This predictable relationship allows technicians to determine system temperatures by reading pressures, and vice versa.

Several factors affect these pressure readings in real-world applications. Ambient temperature has the most significant impact – as outdoor temperature rises, both high and low side pressures increase proportionally. This is why you’ll see different pressure readings on the same system at different times of day or in different seasons.

Key Factors Affecting R22 System Pressures

1. Ambient Temperature: Higher outdoor temperatures increase both condenser and evaporator pressures. A good rule of thumb is that high-side pressure will be approximately 30-40 psig higher than ambient temperature in Fahrenheit.
2. System Load: Higher cooling loads increase pressure differentials across the system. This is why pressures rise during peak heat hours.
3. Airflow: Restricted airflow across evaporator or condenser coils causes pressure abnormalities. Dirty condensers typically cause high head pressure, while frozen evaporators cause low suction pressure.
4. Refrigerant Charge: Overcharged systems run higher pressures, while undercharged systems run lower pressures. Both conditions reduce efficiency and can damage equipment.
5. Altitude: Higher elevations slightly reduce pressure readings due to lower atmospheric pressure. At 5,000 feet elevation, subtract approximately 2.5 psig from sea level readings.

Using R22 PT Charts for System Charging and Diagnostics

Proper use of PT charts is fundamental to accurate refrigerant charging and system diagnosis. After spending decades in the field, I’ve developed systematic approaches that ensure accurate results every time. The key is understanding that PT charts provide reference points, but real-world conditions require interpretation and experience.

Superheat Charging Method

Superheat is the temperature increase above saturation point and is the preferred charging method for fixed metering devices. To calculate superheat, measure the suction line temperature and compare it to the evaporator saturation temperature from your PT chart based on suction pressure.

For example, if your suction pressure is 70 psig, the PT chart shows this corresponds to 40°F saturation temperature. If your suction line temperature measures 50°F, you have 10°F of superheat (50-40=10). This would indicate proper charging for most residential air conditioning applications.

Subcooling Charging Method

Subcooling is the temperature decrease below saturation point and is used for systems with thermostatic expansion valves (TXVs). To measure subcooling, compare liquid line temperature to the condenser saturation temperature from your PT chart based on liquid line pressure.

Proper subcooling for R22 systems typically ranges from 8-12°F. For instance, if your liquid line pressure is 225 psig, the PT chart indicates approximately 100°F saturation temperature. If the liquid line measures 90°F, you have 10°F of subcooling (100-90=10), indicating proper charging.

System Diagnostics Using PT Charts

PT charts are invaluable diagnostic tools. I regularly use pressure readings combined with temperature measurements to identify system problems quickly. Here are my go-to diagnostic procedures:

• Low Suction Pressure: Check for undercharge, restricted airflow, metering device issues, or compressor problems
• High Suction Pressure: Look for overcharge, bad compressor valves, or restricted condenser airflow
• High Head Pressure: Investigate dirty condenser, overcharge, non-condensable gases, or recirculation
• Low Head Pressure: Check for undercharge, bad compressor valves, or low ambient conditions

R22 Pressure Troubleshooting Guide

Through years of field experience, I’ve developed systematic troubleshooting procedures that efficiently identify and resolve pressure-related problems in R22 systems. The key is understanding what normal pressures should be and recognizing deviations that indicate specific issues.

Normal R22 operating pressures vary with ambient temperature, but generally follow these patterns: At 85°F ambient, expect approximately 75-85 psig on the low side and 250-275 psig on the high side. These pressures increase roughly 5-7 psig for every 10°F increase in ambient temperature.

Common Pressure Problems and Solutions

1. Symptom: Low suction pressure (below 60 psig at 75°F ambient)


   Causes: Undercharge, restricted airflow, frozen evaporator, faulty metering device




   Solutions: Check refrigerant charge, clean filters and coils, verify airflow, inspect metering device



2. Symptom: High suction pressure (above 85 psig at 75°F ambient)


   Causes: Overcharge, bad compressor valves, oversized TXV, low load conditions




   Solutions: Recover excess refrigerant, perform compressor valve test, check TXV sizing



3. Symptom: High head pressure (above 300 psig at 75°F ambient)


   Causes: Dirty condenser, overcharge, non-condensable gases, recirculation




   Solutions: Clean condenser, recover excess refrigerant, purge non-condensables, check airflow patterns



4. Symptom: Low head pressure (below 225 psig at 75°F ambient)


   Causes: Undercharge, bad compressor valves, low ambient conditions




   Solutions: Add refrigerant to proper charge, test compressor efficiency, consider low ambient controls




Diagnostic Workflow

When troubleshooting R22 pressure issues, follow this systematic approach:

1. Verify proper operation of all components (fans, compressor, controls)
2. Check and clean air filters and coils
3. Measure temperature differences across coils
4. Compare actual pressures to PT chart expectations
5. Calculate superheat and/or subcooling
6. Identify the specific deviation from normal
7. Address the root cause, not just the symptom

R22 vs Alternative Refrigerants: Pressure Comparison

With the phase-out of R22, many technicians are working with replacement refrigerants. Understanding pressure differences is crucial when retrofitting systems or servicing newer equipment. The most common replacement, R410A, operates at approximately 60% higher pressures than R22.

Temperature	R22 Pressure (PSIG)	R410A Pressure (PSIG)	Pressure Difference
40°F	94.9	151.0	+56.1 psig
50°F	106.2	169.5	+63.3 psig
60°F	118.6	189.6	+71.0 psig
70°F	132.2	211.4	+79.2 psig
80°F	146.9	235.0	+88.1 psig
90°F	162.7	260.6	+97.9 psig
100°F	179.8	288.4	+108.6 psig

These pressure differences mean that R410A systems require different components – stronger condensers, compressors, and tubing rated for higher pressures. Never mix refrigerants or attempt to charge an R22 system with R410A, as this will cause system failure and potential safety hazards.

When working with R22 systems that are being retrofitted, always follow manufacturer guidelines and EPA regulations. Some systems can be converted to alternative refrigerants like R407C, which has pressure characteristics more similar to R22, but efficiency may be reduced.

For proper system diagnosis and charging, having reliable HVAC gauges is essential. Quality manifold gauge sets allow accurate pressure readings necessary for using PT charts effectively. Additionally, refrigerant leak detectors are important tools for maintaining proper system pressures and identifying issues that may cause pressure problems.

Frequently Asked Questions

Final Recommendations

Mastering R22 pressure-temperature relationships is essential for HVAC technicians working with legacy systems. While R22 is being phased out, millions of systems still rely on this refrigerant, and proper understanding of PT charts remains valuable for maintaining existing equipment and transitioning to alternatives.

My experience shows that the most successful technicians combine PT chart knowledge with practical field experience, understanding how real-world conditions affect theoretical pressures. Always verify your readings against normal operating ranges and consider all system factors when diagnosing problems.

For accurate pressure measurements and system diagnostics, investing in quality equipment is crucial. Reliable manifold gauges, proper thermometers, and regular calibration ensure accurate readings necessary for effective troubleshooting and charging procedures.

Remember that PT charts provide reference data, but successful HVAC work requires understanding system dynamics, environmental factors, and the practical aspects of equipment operation. Use this guide as a foundation, but continue building your knowledge through hands-on experience and ongoing education in HVAC technology.
